HDL 26-A
ACTIVE TWO WAY LINE ARRAY MODULE
Product Summary
The RCF HDL26-A is an ultra-compact bi-amped two-way active touring system for small and medium-sized events, both indoors and outdoors. Due to the advanced transducer design and the 2000W Class-D amplifier, among the best in its class, it is capable of an extended bottom-end and a pristine sound for a wide range of applications, alone or in RDNet managed line-array configurations. The HDL 35-AS is the ideal flyable bass complement for the HDL 26-A array system.
Product Description
2000 W Two-Way Amplifier
133 dB Max SPL
1.5” Titanium Compression Driver
2 x 6” High-Powered Neodymium Woofers
Exclusive FiRPHASE technology on-board
750 Hz Crossover for best vocal reproduction
remote monitoring and control
Product Specification
ACOUSTICAL SPECIFICATIONS
Frequency Response: 55 Hz ÷ 20000 Hz
Max SPL @ 1m: 133 dB
Horizontal coverage angle: 100°
Vertical coverage angle: 10°
INPUT/OUTPUT
Input signal: bal/unbal
Input connectors: XLR, RDNet Ethercon
Output connectors: XLR, RDNet Ethercon
Input sensitivity: +4 dBu
POWER SECTION
Total Power: 2000 W Peak, 1000 W RMS
High frequencies: 600 W Peak, 300 W RMS
Low frequencies: 1400 W Peak, 700 W RMS
Cooling: Convection
Connections: Powercon IN/OUT
PHYSICAL SPECIFICATIONS
Hardware: Array fittings
Handles: 2 Back
Color: Black, White
SIZE
Height: 237 mm / 9.33 inches
Width: 470 mm / 18.5 inches
Depth: 377 mm / 14.84 inches
Weight: 13.5 kg / 29.76 lbs
